Renewable Energy Step-up Substation
Step-up package coordinated for solar and wind collection systems and destination grid requirements.
Technical details +
← All productsEnergy Storage & Step-up Systems
BESS PCS & Step-up Integrated System
Coordinated PCS, transformer and medium-voltage package for battery energy storage projects.
OVERVIEW
Configured for the actual electrical system.
The interface review aligns battery DC voltage, PCS rating, transformer impedance, auxiliary loads, harmonic limits, protection, communications, enclosure and grid-code requirements across selected partners.
Typical ranges on this page are for preliminary project selection only. Final design, materials, performance, tests, certificates and supply scope are subject to the signed project technical agreement and the selected manufacturing partner.
TECHNICAL DATA
Typical configuration range.
Final values, losses, dimensions and accessories are confirmed in the project proposal.
| Parameter | Specification |
|---|---|
| Typical AC power block | 500 kW-5 MW |
| Typical MV output | 6-35 kV |
| Integration | PCS + transformer + MV switchgear |
| Frequency | 50 / 60 Hz |
| Cooling | Project-specific |
| Grid interface | Utility and local-code review |
| Specification status | Typical reference; final values per signed project technical agreement |
CONFIGURATION INPUTS
The data that shapes the proposal.
01Voltage & capacity
02Frequency & phase
03Vector group & impedance
04Loss & temperature-rise target
05Site environment
06Applicable standard
PROJECT WORKFLOW
From specification to dispatch.
01Requirement review
02Technical proposal
03Partner manufacturing
04Inspection / FAT
05Packing & delivery
