Ring Main Unit
Compact medium-voltage distribution and protection options for utility, commercial and renewable-energy networks.
OVERVIEW
Configured for the actual electrical system.
Feeder arrangement, load-break switches, circuit breakers, fuses, metering, automation interfaces and insulation technology are selected around the network scheme and local rules.
Typical ranges on this page are for preliminary project selection only. Final design, materials, performance, tests, certificates and supply scope are subject to the signed project technical agreement and the selected manufacturing partner.
TECHNICAL DATA
Typical configuration range.
Final values, losses, dimensions and accessories are confirmed in the project proposal.
| Parameter | Specification |
|---|---|
| Typical voltage class | 12 / 24 / 36 kV |
| Typical rated current | Up to 630 A |
| Typical short-circuit rating | 16-25 kA |
| Insulation | Air / gas / solid options |
| Arrangement | Extensible / non-extensible options |
| Reference standard | IEC 62271 series or project requirement |
| Specification status | Typical reference; final values per signed project technical agreement |
CONFIGURATION INPUTS
The data that shapes the proposal.
01Voltage & capacity
02Frequency & phase
03Vector group & impedance
04Loss & temperature-rise target
05Site environment
06Applicable standard
